Overview
Technological innovation has given birth to new ways to index workpieces. Two examples are servomotor-driven multiple-axis control and cooperative control. Computerized control is another important technology for sophisticated machines, but complex systems do not alleviate problems of running costs and daily maintenance. That's where Kawata got to thinking. Isn't there a way to make sound quality products more easily and with greater precision? There is. We've stripped down workpiece indexing to only the true bare essentials.
Features
* No power necessary!
Full mechanical control means drive power is not needed. No more troubles with connections, grounding or trying to secure a power supply.
* Requires little installation space!
Because there is no control unit, TOUCHDEX needs only minimal installation space. It makes even the bulkiest of machines look more compact.
* Easy to build-in!
There are no cables to connect, so TOUCHDEX is easily incorporated into your machine. It can also be used with pallet changers, too.
* Excellent cost-performance!
Thanks to simple construction electrical parts, TOUCHDEX is priced about the same as other commercially available manual indexing units.
* Great durability! Designed and built to be tough,
TOUCHDEX will give you long-lasting performance. Lock pins are used to clamp parts, so you have more than enough durability for even heavy duty cutting.
How TOUCHDEX Works
*Angle Indexing
TOUCHDEX is so simply constructed that it can be used on any machine by anyone as soon as it is installed. And, machining is further enhanced when TOUCHDEX is coupled with options or other TOUCHDEX units.
The pushbar on the right end is pushed by a machine center tool.
When pushed by the tool, the table indexes the angle preset for the tool's stroke.
As the pushbar retracts, the tool is automatically clamped.
Indexing time: Approx. 1 sec Speed: Min. 5000 mm/sec (Set to less than half if tool is unbalanced.)
Higher Precision Indexing
*Higher Precision Indexing>
If the push distance of the pushbar is set in the machine center's
program, indexing is possible in an angle of 5 increments.>
With the FDM-230-360、FD-200-360、FD-300-360
ndexing is possible to an unbelievable an angle of 1accuracy!>
This offers users the precision needed for delicate machining control.
*Indexing Programming （with FDM-200-04）
With a full indexing stroke (78 mm) of approximately
an angle of 90, indexing is possible to an angle of 5 by
pushing 18.5 mm, or to an angle of 10 by pushing 22
mm. Lock release stroke (15) + (Rotational stroke
78 - Lock release stroke 15)/18 = 15 + 3.5 = 18.5
15 + 2/18 (Rotational stroke) = 22 mm
>BACK
About Licenses In and Outside Japan
TOUCHDEX is licensed for use not only Japan but overseas as well. It is already being used in many countries around the world and has been highly recognized for its sound performance and reliability.
